Installation

The information on this page should be considered as general advice only.

ACO offers this guidance in good faith and if in doubt, engineering advice should be sought.

1. Typical installation drawings
2. Site specific topics

1. Typical installation drawings

Polycrete^® Pits

Description	Nominal Wheel Load (kg)	Cover Type	PDF	DWG
Polycrete^® Pit	330	Lid
	2670	Lid
	2670	Cover & frame
	5000	Lid
	5000	Cover & frame
	8000	Cover & frame
	30000	Cover & frame

Polyethylene pits

Description	Nominal Wheel Load (kg)	Cover Type	PDF	DWG
Plastic Pit	330	Lid
	2670	Lid
	2670	Cover & frame
	5000	Cover & frame

SCEC pits

Description	Nominal Wheel Load (kg)	Application	PDF	DWG
Concrete Pit	2670	Grass
	8000	Grass
	8000	Concrete

EzyBrixx^®

Description	PDF	DWG
EzyBrixx^® Pits for highly trafficked 8000kg SMWL
EzyBrixx^® Pits 8000kg SMWL
EzyBrixx^® Pits for occasionally trafficked pavements

Polypropylene pit material properties

Tensile	= 23MPa
Tensile modulus	= 1.05 GPa
Flexural Strength	= 33Mpa
Flexural Modulus	= 1.24GPa
Impact Strength (notched)	= 4.27 J/cm
Density	= 0.9gm/cm3
Flammability UL94	= HB @ thickness 3.17mm
Volume resistivity	> 1.00 E+15 ohm-cm

SIT pits

Description	PDF
SIT Pits installation

Surface ducting channels

Description	Nominal Wheel Load (kg)	Application	PDF	DWG
CD Series	330	Asphalt
	330	Concrete
	330	Grass
	330	Pavers
	2670	Asphalt
	2670	Concrete
	2670	Grass
	2670	Pavers
CS Series	8000	Asphalt
	8000	Concrete
	8000	Pavers
	> 8000	Ashphalt
	> 8000	Concrete
	> 8000	Pavers

2. Site specific topics

Polycrete^® Pits

Polyethylene pits

SCEC pits

EzyBrixx^®

Methodology

Surface ducting channels

Access Cover
